How to Fit a Fused Spur: A Comprehensive Guide by RCD Electrical
Fitting a fused spur is a common electrical task that allows you to add a new power outlet or appliance to your home’s electrical system. Whether you’re installing a new socket for a kitchen appliance, an outdoor power supply, or a dedicated circuit for a high-power device, a fused spur provides a safe and reliable solution. At RCD Electrical, your trusted North London electricians, we believe in empowering homeowners with knowledge while emphasising the importance of safety and compliance with UK electrical regulations. This guide will walk you through the process of fitting a fused spur, offering step-by-step instructions, safety tips, and professional insights.
Please note that working with electricity is inherently dangerous, and UK regulations (Part P of the Building Regulations) require that certain electrical work be carried out or certified by a qualified electrician. Unless you are a competent professional, we strongly recommend hiring a certified electrician, such as the team at RCD Electrical, to perform this task.
ELECTRICAL INSTALLATION AND MAINTENANCE IN NORTH LONDON
What Is a Fused Spur?
A fused spur is an electrical component that provides a connection point for an appliance or device, typically branching off from an existing ring main or radial circuit. It contains a fuse (usually 13A, but can vary depending on the appliance) to protect the circuit from overloading. Fused spurs are commonly used for fixed appliances like electric heaters, ovens, or outdoor lighting, where a standard plug socket isn’t suitable.
There are two main types of fused spurs:
-
Switched Fused Spur: Includes an on/off switch for controlling the connected appliance.
-
Unswitched Fused Spur: Lacks a switch, meaning the appliance is always powered when the circuit is live.
Understanding the type of fused spur you need is the first step in the installation process.
Why Install a Fused Spur?
Fused spurs are versatile and offer several benefits:
-
Safety: The built-in fuse protects the appliance and circuit from electrical faults.
-
Convenience: They allow you to add a power source without installing a full socket or rewiring the circuit.
-
Compliance: When installed correctly, fused spurs meet UK electrical standards, ensuring your home is safe and legal.
-
Aesthetics: Fused spurs are discreet and blend seamlessly into your home’s decor.
Whether you’re upgrading your kitchen or adding outdoor lighting, a fused spur is a practical solution.
Tools and Materials Needed
Before starting, gather the following tools and materials:
-
Fused spur unit (switched or unswitched, depending on your needs)
-
Appropriate fuse (e.g., 13A for most appliances)
-
Electrical cable (2.5mm² twin and earth for most domestic applications)
-
Screwdrivers (flathead and Phillips)
-
Wire strippers
-
Voltage tester
-
Cable clips or conduit
-
Wall box (metal or plastic, depending on the wall type)
-
Drill and masonry bits (if mounting on a brick wall)
-
Chisel and hammer (for chasing walls)
-
Electrical tape
-
Personal protective equipment (PPE), such as insulated gloves and safety goggles
Ensure all materials comply with British Standards (BS 1363 for fused spurs and BS 7671 for wiring regulations).
Step-by-Step Guide to Fitting a Fused Spur
Follow these steps to fit a fused spur safely and correctly. Always consult a professional electrician if you’re unsure about any part of the process.
Step 1: Plan the Installation
-
Choose the Location: Select a suitable position for the fused spur, ensuring it’s accessible and complies with regulations (e.g., not in a bathroom’s restricted zone).
-
Check the Circuit: Identify the circuit you’ll connect to (ring main or radial). Ensure it can handle the additional load by consulting a qualified electrician.
-
Obtain Permissions: If you’re in a rented property or listed building, get approval from your landlord or local authority.
Step 2: Turn Off the Power
-
Isolate the Circuit: Switch off the main power at the consumer unit (fuse box) and lock it to prevent accidental reactivation.
-
Test for Safety: Use a voltage tester to confirm the circuit is dead before proceeding.
Step 3: Prepare the Wall
-
Mark the Position: Trace the outline of the wall box on the wall where the fused spur will be mounted.
-
Chase the Wall: If running cables through the wall, use a chisel and hammer or a wall chaser to create a channel for the cable.
-
Fit the Wall Box: Secure the wall box (flush or surface-mounted) using screws or wall plugs, ensuring it’s level.
Step 4: Run the Cable
-
Measure and Cut: Cut a length of 2.5mm² twin and earth cable to run from the existing circuit to the fused spur.
-
Route the Cable: Feed the cable through conduit or clip it to the wall, following safe zones (vertically or horizontally aligned with the spur).
-
Connect to the Circuit: If connecting to a ring main, you’ll need to break into the circuit. This is complex and should only be done by a qualified electrician.
Step 5: Wire the Fused Spur
-
Strip the Wires: Use wire strippers to expose the live (brown), neutral (blue), and earth (green/yellow) wires.
-
Connect the Wires:
-
Supply Side: Connect the incoming cable (from the circuit) to the “Supply” or “In” terminals (Live to L, Neutral to N, Earth to E).
-
Load Side: Connect the outgoing cable (to the appliance) to the “Load” or “Out” terminals.
-
Insert the Fuse: Open the fused spur unit and insert the correct fuse (e.g., 13A).
-
Secure the Unit: Screw the fused spur unit into the wall box.
Step 6: Test the Installation
-
Double-Check Connections: Ensure all wires are secure and no bare conductors are exposed.
-
Restore Power: Turn the power back on at the consumer unit.
-
Test the Spur: Use a voltage tester to confirm the spur is functioning correctly. If it’s a switched spur, test the switch.
-
Check the Appliance: Connect the appliance and verify it works as expected.
Step 7: Finalise and Certify
-
Tidy Up: Secure any loose cables and fill in chased walls with plaster or filler.
-
Certify the Work: Under Part P regulations, electrical work must be tested and certified by a competent person. Contact RCD Electrical to certify your installation.
Safety Tips
-
Always turn off the power before starting work.
-
Use insulated tools and wear PPE.
-
Avoid overloading circuits; consult an electrician to check load capacity.
-
Never work on live circuits.
-
If in doubt, hire a professional electrician.
Common Mistakes to Avoid
-
Incorrect Wiring: Mixing up live, neutral, and earth connections can cause faults or fires.
-
Using the Wrong Fuse: Always match the fuse rating to the appliance’s requirements.
-
Ignoring Regulations: Non-compliant work can invalidate insurance and pose safety risks.
-
Poor Cable Routing: Cables outside safe zones are vulnerable to damage.
When to Call a Professional
While DIY electrical work can be tempting, fitting a fused spur involves complex wiring and strict regulations. Mistakes can lead to electrical shocks, fires, or legal issues. At RCD Electrical, our team of certified electricians in North London is trained to handle fused spur installations safely and efficiently. We ensure compliance with BS 7671 and Part P, giving you peace of mind.
Conclusion
Fitting a fused spur is a practical way to extend your home’s electrical system, but it requires careful planning, the right tools, and strict adherence to safety standards. By following this guide, you can better understand the process, but we strongly recommend hiring a professional for the actual installation. At RCD Electrical, we’re committed to delivering safe, reliable electrical solutions across North London.
