A short circuit is a low-resistance fault that can allow a very high current to flow between conductors. A ground fault, usually called an earth fault in the UK, sends current along an unintended path to earth. An arc fault involves current passing across a gap or poor connection as an electrical arc, producing intense localised heat.
These terms describe different fault paths and behaviours, but they are not always completely separate. A line-to-earth fault may produce both high fault current and residual current, while an electrical arc can develop as part of another fault. The protective device that operates depends on the circuit design, the fault path and the amount of current involved.
Key Takeaways
- Short circuits normally involve an unintended low-impedance connection and can produce a large overcurrent.
- Ground faults are generally described as earth faults in UK electrical terminology and involve current flowing towards earth.
- Arc faults involve unstable electrical arcing, often around damaged cables or poor connections.
- MCBs, fuses, RCDs, RCBOs and AFDDs perform different protective functions; one device does not automatically cover every fault type.
- Repeated tripping, burning smells, scorch marks, unusual heat or crackling sounds should be investigated rather than repeatedly reset or ignored.
Short Circuit, Ground Fault and Arc Fault Differences at a Glance
Swipe left or right to view all columns ↔
The table is useful for comparison, but protective devices should not be treated as a simple one-device-per-fault system. Fault current can take different paths, and more than one protective function may respond to the same event.
What Is a Short Circuit?
A short circuit occurs when an unintended connection creates a much lower resistance path than the circuit is designed to have. In a typical single-phase installation this may involve line and neutral conductors coming into contact because insulation has failed or wiring has been damaged.
The resulting current can rise rapidly. Circuit-breakers and fuses are designed to provide overcurrent and short-circuit protection, disconnecting the affected circuit when their operating conditions are reached.
Possible signs include:
- a circuit-breaker operating suddenly;
- a fuse rupturing;
- visible sparking or damaged wiring;
- scorching around an accessory;
- a burning smell or evidence of overheating.
A protective device operating is a symptom, not a diagnosis. The cause still needs to be identified before damaged wiring or equipment is returned to service.
What Is a Ground Fault or Earth Fault?
In UK electrical work, earth fault is the more familiar term. It describes fault current flowing from a live conductor towards earth, which can include current reaching exposed conductive parts that should not normally be live.
Electrical Safety First explains that earthing provides a path for fault current and helps the appropriate protective device disconnect the faulty circuit. An RCD works differently from an ordinary overcurrent device: it monitors current balance and can disconnect the supply when current is taking an unintended path.
An earth fault can result from damaged insulation, water ingress, a damaged cable, faulty electrical equipment or a conductor contacting an earthed metal part.
Important distinction: an RCD is not simply a substitute for a circuit-breaker. An RCBO combines residual-current protection with overcurrent protection, while separate RCDs and circuit-breakers perform different functions.
What Is an Arc Fault?
An arc fault occurs when electrical current crosses a gap or unstable connection rather than flowing cleanly through a sound conductor and secure termination. The arc can create substantial localised heat, which is why damaged cables and poor electrical connections can present a fire risk even when the current does not behave like a conventional high-current short circuit.
Conditions associated with unwanted arcing can include:
- loose electrical connections;
- damaged or crushed cables;
- deteriorated insulation;
- poorly secured terminations;
- conductors damaged by screws, nails or other mechanical impact.
Arc Fault Detection Devices, or AFDDs, are designed to identify characteristics associated with dangerous arcing and disconnect the affected circuit where their operating conditions are met. They provide a different protective function from an ordinary circuit-breaker or RCD and do not remove the need for the other protection required by the installation.
Which Protective Device Responds to Each Fault?
The safest way to understand the difference is to look at what each protective device is intended to detect.
Fuses and circuit-breakers
These provide protection against excessive current, including overload and short-circuit conditions. A sufficiently high fault current causes the protective device to disconnect according to its characteristics.
RCDs
RCDs monitor whether current is returning through the expected path. An imbalance can indicate current flowing elsewhere, including through an earth fault. This provides important protection against electric shock and some electrical fire risks.
RCBOs
An RCBO combines residual-current protection and overcurrent protection in one device. It can therefore respond to different conditions from an RCD-only device.
AFDDs
AFDDs are intended to detect dangerous arcing characteristics. Their application forms part of electrical design under the IET Wiring Regulations rather than being a general replacement for circuit-breakers, RCDs or RCBOs.
The IET currently publishes BS 7671:2018+A4:2026 as the latest amendment to the Wiring Regulations. Device selection and circuit protection should therefore be assessed against the applicable current requirements and the installation itself.
What Warning Signs Should You Take Seriously?
You normally cannot identify the exact fault type from one symptom alone. A circuit-breaker that trips, for example, does not prove that the problem is a short circuit. The same visible symptom can have several possible causes.
Warning signs that justify investigation include:
- repeated circuit-breaker, RCD or RCBO operation;
- crackling, buzzing or arcing sounds;
- burn marks or discolouration around sockets or switches;
- an accessory or consumer-unit component becoming unusually hot;
- persistent burning smells;
- visible cable damage or exposed conductors;
- intermittent loss of power on a circuit.
Electrical Safety First advises against ignoring burn marks, arcing sounds, repeated protective-device operation or excessive heat. The IET also cautions against repeatedly resetting a circuit-breaker or RCD when a fault continues.
Do not repeatedly reset a protective device to keep a faulty circuit running.
If there is active sparking, smoke, significant overheating, exposed live parts or a strong electrical burning smell, stop using the affected equipment or circuit and arrange
urgent electrical help.
For observations that can be made without opening electrical equipment or carrying out live testing, see
how to safely identify electrical faults before calling an electrician.
How Does an Electrician Identify the Actual Fault?
Professional diagnosis is based on the behaviour of the circuit and appropriate inspection and testing, rather than assuming the fault type from a tripped switch or damaged accessory.
Depending on the problem, this can involve checking the condition of wiring and connections, insulation, protective conductors, circuit continuity, protective devices and the affected equipment. Testing is selected according to the fault and should not be treated as a homeowner live-testing procedure.
The separate guide to
common electrical fault detection methods
explains the diagnostic methods in more detail.
If a circuit repeatedly trips, loses power, overheats or shows other unexplained symptoms, RCD Electrical can
have the electrical fault investigated
before repair or replacement work is decided.
